Description

What is a 110mm Drainage Elbow used for?

A 110mm drainage elbow with a 30-degree angle is a specialized fitting used to create shallow turns in an underground sewer or surface water system. While 45 and 90-degree bends are common for major turns, the 30-degree 110mm drainage elbow is essential for precision alignment, allowing installers to navigate around underground obstructions or transition pipes into manholes and inspection chambers with ease.

Advantages of the Single Socket 30-Degree Design

This specific 110mm drainage elbow is a “single socket” fitting. It consists of one socketed end equipped with a high-quality captive rubber seal and one plain spigot end. This configuration is incredibly useful for “socket-to-spigot” installations, where the elbow needs to be inserted directly into the socket of an existing 110mm pipe or another fitting. The push-fit mechanism ensures a watertight seal that remains flexible enough to accommodate minor ground movement or thermal expansion.

Built for Professional Underground Installations

At ECO HEAT SHOP, we ensure our drainage components are built to last. This 110mm drainage elbow is manufactured from heavy-duty PVC-U (Unplasticized Polyvinyl Chloride), making it naturally resistant to the acidic and alkaline conditions found in UK soil. It is fully compliant with UK building regulations for gravity-fed underground drainage, providing a reliable, leak-proof solution that eliminates the need for messy solvent cements.

Technical Specification & Installation Tips

• Product Name: 110mm Drainage Elbow

• Angle: 30 Degrees

• Joint Type: Single Socket (1 Socket, 1 Spigot)

• Material: Heavy-Duty PVC-U (Terracotta/Orange)

• Installation Advice: When installing your 110mm drainage elbow, ensure the spigot end is fully chamfered and free of debris. Always use a silicone-based lubricant on the pipe ends before insertion to prevent the captive rubber seals from twisting or dislodging during the push-fit process.
