Canadian Solar 550W Silver Frame Solar Panel

✔️ Cell: Mono-crystalline

✔️ Weight: 27.6kg

✔️ Dimensions: 2278 x 1134 x 30mm

✔️ No. of Cells: 144 (2x (12×6))

✔️ Maximum Power: 550W

✔️ 12-year product warranty

✔️ 25-year linear power output warranty

✔️ Comes with MC4-EVO2 Connectors.

Price Available on Request

Request Your PriceView basket
Categories: , , , ,

Description

Details

The Canadian Solar 550W Mono-Crystalline Panel is a high-performing large-scale solar panel with up to 550W of power. It is suited to commercial and utility-level solar farms, featuring comprehensive LeTID and LID mitigation technology, to ensure up to 50% less degradation than other panels.

Part No: CS6W-550

Technical Data

Cell: Mono-crystalline

Weight: 27.6kg

Dimensions: 2278 x 1134 x 30mm

No. of Cells: 144 (2x (12×6))

Maximum Power: 550W

Maximum Power Voltage: 41.7v

Maximum Power Current: 13.20A

Efficiency: 21.3%

Certification:
IEC 61215 / IEC 61730 / CE UL 61730 / IEC 61701 / IEC 62716 / Take-e-way
ISO 9001: 2015
ISO 14001: 2015
ISO 45001: 2018
IEC62941: 2019

Warranty:
12-year product warranty
25-year linear power output warranty

Comes with MC4-EVO2 Connectors.

PLEASE NOTE: These panels are designed for large commercial solar farms and are not recommended for domestic installation. Additionally these panels require two people to move. When delivering, it’s compulsory for someone fit and able to be there to assist our driver. Our driver will not deliver these panels unassisted and you will be charged for the aborted delivery attempt.

Datasheet

Additional information

Weight 27.6 kg
Dimensions 2278 × 1134 × 30 mm
